KLTK-H7

• Powered by Kubota • 4 stages mast up to 9 meters

Availability:
sharethis sharing button

KLT-6700T

KLTK-V7

KLTY-V7

KLTK-H7

KLTK-C7




Features


Wide Lighting Area

LEES’s light tower parallel lamp structure is more efficient than competitive lighting systems and provides up to 50% more light output. The unique top structure of the lamp shade directs up to 10% of previously wasted upward light directly to the work site.


Dual Application

The generator powering the light tower can be used a backup power in emergency situations. There are two receptacles on the light tower mast. You can switch off the lights and then connect another electrical load to get a quality output from the generator.

The receptacles can be configured to your voltage requirement of 120, 230, or 240V.


Advantages of Halide Lamp

The internal structure of the metal halide lamp is unique. The light is produced through the discharge of its internal gasses. There is no filament to break or deteriorate over time and no bulb to throw away.


Safe operation

The mast incorporates a safety feature by not permitting the mast to be raised unless the footbrake is on. If the footbrake is release, the mast will automatically lower to the travel position. The light tower trolley has stabilizers to keep the light tower steady on all surfaces.



KLTK-H7

Light Tower




Mast Height

m

9

9

Frequency

Hz

50

60

Rated voltage

V

230

240/120

Rated power

kW

6

7

Max.Output

kW

7

8

Power Outlet Sockets


2*16A

2*16A

Fuel Consumption

L/H

1.7

1.7

Fuel Tank Capacity

L/H

40

40

Fuel Tank Hours


23

23

Noise Level

(7m)dB(A)

74

74

Weight

KGS

1630

1630

Dimension in Operation(L x W x H)

mm

2400x1800x9000

2400x1800x9000

Dimension in Transport (L x W x H) disassembly

mm

2400x1800x2540

2400x1800x2540

Load Capacity in 20FT (units) disassembly


/

/

Load Capacity in 40HQ (units) disassembly


4

4

Engine




Engine brand


Kubota

Kubota

Engine model


D1105-E2BG

D1105-E2BG

Speed

rpm

1500

1800

Prime Power

kw

8.4

10.1

Cooling System


Water-cooled

Water-cooled

Oil capacity


5.1

5.1

Alternator




Alternator Brand


Mecc alte

Mecc alte

Alternator Model


LT3N-130/4

LT3N-130/4

Continued Power

kVA

7

8

Excitation mode


Capacitor exciter

Alternator Insulation


H

H

Protection Grade


IP23

IP23

Mast




Mast type


Hydraulic

Hydraulic

Section No. (Extened)


8

8

Mast Rotation


359°

359°

Mast Extension Time


14 seconds

14 seconds

Mast Descend Time


10 seconds

10 seconds

Lighting




Type of lights


Metal halide lamp

Metal halide lamp

Number & Power of the lights


4*1000W

4*1000W

Mast Lighting & Extension


Hydraulic operation

Hydraulic operation

Mast Lighting & Extension


Hydraulic operation

Hydraulic operation

Light angle turning


Electric

Electric

Luminous flux


4*110000=440000

IIIum Area (5 Lux min)


3900

3900

Lamps Rotation


75° (Automatic)

75° (Automatic)

Protection Glass


IP33

IP33

Color Temperature


4200K

4200K

Trailer




Braking System


Parking braking

Parking braking

Hitch


 Ball type/O Ring option

Tire Rim Size


185/R14''

185/R14''

Speed


<80km/h

<80km/h
